Hantel Tech Webinar Series: Although in MFA software three type of molds are available for simulation, but in present tutorial part only mold is selected. Selection of injection location is very important part for plastic injection molding analysis. All data must be provided by user.

Uploader: Meztiran
Date Added: 16 December 2016
File Size: 55.35 Mb
Operating Systems: Windows NT/2000/XP/2003/2003/7/8/10 MacOS 10/X
Downloads: 10718
Price: Free* [*Free Regsitration Required]





Figure 2 d Process selection. Want more information after viewing this video?

Auto-desk MFA software has huge list of plastic materials used in P. In this tutorial I will show you how to set up a single cavity analysis with a complete feeding system gate, runner and sprue in Autodesk MoldFlow Adviser. This video shows a demo of the new Gate Location analysis in Autodesk Moldflow Adviser which can search for up to 10 injection points simultaneously while excluding user-specified regions of the part that are not suitable for gating.

Tutorial 1 Plastic Injection Molding (PIM) using Autodesk Moldflow Adviser | grobdesign

Figure 2 c Run advance topic. As seen figure 7 material can select by using manufacturer and trade name provided in this wizard. The basic difference between both tools are geometry used for simulation. Hantel Tech Webinar Series: To avoid high costs and time delays associated with plastic part manufacturing, it is necessary to consider the combined effects of.

This tutorial shows how to handle a coreshift in Autodesk Simulation Moldflow Step 6 Material Molfdlow. Enter text only if you are not human: May 25 - July 3, 7-Weeks.

Summer Training Su mmer Training School. Moldfloa Moldflow is the first plastic injection molding simulation software with Fill Preview technology, a groundbreaking new feature that shows how a plastic part will fill and where weld lines will occur in near real time.

Thanks for reading this blog. For actual results advance molds are necessary. When hot plastic is injected into a cold mold, the mold steel that is in contact with the plastic will heat up very quickly and then cool down slowly a. By default fill and pack type simulation is selected in software.

Figure 8 Search window in MFA software. Mike Smell walks you through how to define a gate location and determine better gate locations for your plastic parts in Autodesk Simulation Moldflow. During working on CAD geometry making please focus on some points like remove all unnecessary lines, curves, surfaces from main file.

Moldflow Insight Tutorials

Step 8 Selection of Analysis Sequences. MFA required various process parameter settings like mold temperature, melt temperature, injection pressure, packing pressure, injection velocity and many more. Figure 9 Boundary Conditions.

Step 5 Injection Location. MFA have two type of processing tools for simulation.

Moldflow Adviser Tutorials

Note down all dimensional parameters of geometry. True 3D is only used when thick or chunky bodies are used for simulation otherwise dual domain is used. Be sure to visit www. Finally run analyze command for results.

So please take care of this step. Figure 2 b Unit Selection. Simulation in Auto-desk MFA software is performed step by step which are tytorial.

So data accuracy is needed in this step. In current project step 1 import cad file is completed.
